Non-Insulated
PC Jacks

09-9280-1-04
09-9280-1-04
09-9280-1-04
0.040 0.190 " 0.388" Jack/Turret Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9249-1-04
09-9249-1-04
09-9249-1-04
0.030 0.245 " 0.525" Jack/Pin Solder - 1/32 - 1/16 0.043 Brass Electro-Tin Vertical
09-9178-1-03
09-9178-1-03
09-9178-1-03
0.040 0.187 " 0.270" - Solder - 1/32 - 3/16 0.073 Brass Gold Vertical
09-9008-1-04
09-9008-1-04
09-9008-1-04
0.040 0.192 " 0.317" - Solder - 1/32 - 3/32 0.089 Brass Electro-Tin Vertical
09-9002-1-06
09-9002-1-06
09-9002-1-06
0.040 0.207 " 0.236" - Solder - 1/32 - 1/8 0.089 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9618-1-03
09-9618-1-03
09-9618-1-03
0.032 - 0.046 0.195 " 0.236" - Solder - 1/16 - 5/32 0.089 Brass Gold Vertical
09-9048-1-06
09-9048-1-06
09-9048-1-06
0.040 0.210 " 0.238" - Solder - 1/32 - 5/32 0.104 Brass Electro-Tin Vertical
09-9039-1-063
09-9039-1-063
09-9039-1-063
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.144 Brass Bright Tin-Lead Vertical
09-9002-1-04
09-9002-1-04
09-9002-1-04
0.040 0.207 " 0.236" - Solder - 1/32 - 1/8 0.089 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9001-1-0355
09-9001-1-0355
09-9001-1-0355
0.040 0.190 " 0.206" - Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Gold Vertical
09-9278-1-06
09-9278-1-06
09-9278-1-06
0.025 0.093 " 0.140" - Solder - 1/32 0.062 Brass Electro-Tin Vertical
09-9287-1-063
09-9287-1-063
09-9287-1-063
0.080 0.333 " 0.412" - Solder - 1/32 - 1/4 0.145 Brass Bright Tin-Lead Vertical
09-9047-1-03
09-9047-1-03
09-9047-1-03
0.040 0.186 " 0.233" - Solder - 1/32 - 1/8 0.104 Brass Gold Vertical
09-9662-1-035
09-9662-1-035
09-9662-1-035
0.015 - 0.021 0.055 " 0.083" - Solder - 1/32 0.041 Brass Gold Vertical
09-9626-2-03
09-9626-2-03
09-9626-2-03
0.025 - 0.037 0.180 " 0.397" Jack/Pin Solder - 1/32 - 3/32 0.044 Brass Gold Vertical
09-9623-1-03
09-9623-1-03
09-9623-1-03
0.022 - 0.034 0.060 " 0.090" - Solder - 1/32 0.067 Brass Gold Vertical
09-9245-1-99
09-9245-1-99
09-9245-1-99
0.040 0.190 " 0.206" - Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) LEADED Red Brass Gold Vertical
09-9082-1-088
09-9082-1-088
09-9082-1-088
0.040 0.190 " 0.511" Jack/Pin Solder - 1/32 - 1/8 0.043 Brass Bright Tin-Lead Vertical
09-9273-1-063
09-9273-1-063
09-9273-1-063
0.030 0.165 " 0.250" - Solder - 1/32 - 1/8 0.076 Brass Bright Tin-Lead Vertical
09-9633-1-03
09-9633-1-03
09-9633-1-03
0.065 - 0.082 0.260 " 0.309" - Solder - 1/32 - 1/4 0.159 Brass Gold Vertical
