Commercial
Insulated
Pin Terminals

Filter
1137-03-04417
1137-03-04417
1137-03-04417
0.320" 0.030 Pin/Slotted Press Fit 1/16 0.070 Brass Bright Tin - - PTFE Violet YES
1153-02-0317
1153-02-0317
1153-02-0317
0.515" 0.040 Pin/Pin Press Fit 1/16 0.113 Brass Gold - - PTFE Violet YES
1126-32-0317
1126-32-0317
1126-32-0317
1.172" - - 4-40 Screw - CLEARANCE FOR #4 Screw Brass Gold ZINC Brass PTFE Violet YES
1126-36-0517
1126-36-0517
1126-36-0517
0.890" - - 4-40 Nut 1/8 0.120 Brass Electro Solder ZINC Brass PTFE Violet NO
1177-05-0413
1177-05-0413
1177-05-0413
0.370" 0.040 - PRESS LOCK 1/32 - 1/16 0.158 Brass Electro-Tin - - PTFE Orange NO
1177-05-04413
1177-05-04413
1177-05-04413
0.370" 0.040 - PRESS LOCK 1/32 - 1/16 0.158 Brass Bright Tin - - PTFE Orange NO
1115-04-0117
1115-04-0117
1115-04-0117
0.710" 0.085 - Press Fit 1/8 0.158 Brass Silver - - PTFE Violet YES
1177-05-0513
1177-05-0513
1177-05-0513
0.370" 0.040 - PRESS LOCK 1/32 - 1/16 0.158 Brass Electro Solder - - PTFE Orange NO
1114-21-08817
1114-21-08817
1114-21-08817
0.312" 0.085 - Press Fit 1/32 0.136 Brass Bright Tin-Lead - - PTFE Violet NO
1110R-21-0317
1110R-21-0317
1110R-21-0317
0.515" 0.040 Pin/Pin Press Fit 1/16 0.136 Brass Gold - - PTFE Violet YES
1111-02-0117
1111-02-0117
1111-02-0117
0.535" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.101 Brass Silver - - PTFE Violet YES
1111-07-0317
1111-07-0317
1111-07-0317
0.438" 0.040 DOUBLE Turret/Tip Press Fit 1/16 0.136 Brass Gold - - PTFE Violet YES
1111-57-04417
1111-57-04417
1111-57-04417
0.680" 0.040 - Press Fit 1/8 0.158 Brass Bright Tin - - PTFE Violet YES
1111-59-0317
1111-59-0317
1111-59-0317
0.750" 0.040 DOUBLE Turret/Tip Press Fit 1/8 0.086 Brass Gold - - PTFE Violet YES
1125-19-0317
1125-19-0317
1125-19-0317
0.822" - - 6-32 Nut Up to 3/16 0.144 Brass Gold Electro-Tin Brass PTFE Violet YES
1121-23-04417
1121-23-04417
1121-23-04417
1.965" 0.050 Turret/Tip Press Fit 49/64 0.158 Brass Bright Tin - - PTFE Violet YES
1121R-05-0317
1121R-05-0317
1121R-05-0317
0.493" 0.040 Turret/Tip Press Fit 1/8 0.136 Brass Gold - - PTFE Violet YES
1122-01-04417
1122-01-04417
1122-01-04417
0.250" - - Press Fit 1/64 0.070 Brass Bright Tin - - PTFE Violet YES
1123-03-0317
1123-03-0317
1123-03-0317
0.821" 0.050 TIP/SLOTTED Press Fit Up to 3/16 0.158 Brass Gold - - PTFE Violet YES
1123R-61-0117
1123R-61-0117
1123R-61-0117
0.477" 0.050 Pin/Slotted Press Fit 5/32 0.136 Brass Silver - - PTFE Violet YES
