Military
Non-Insulated
Terminals

Filter
15-214-1-05
15-214-1-05
15-214-1-05
0.209" - Swage Mount 0.053" 1/32 0.067 Brass Electro Solder M55155/30XH02 AA59126/30XH02
15-214-2-095
15-214-2-095
15-214-2-095
0.240" - Swage Mount 0.084" 1/16 0.067 Brass Hot Solder Dip M55155/30XI05 AA59126/30XI05
15R-214-11-088
15R-214-11-088
15R-214-11-088
0.193" - Swage Mount 0.037" 1/64 0.067 Phosphor Bronze Bright Tin-Lead M55155/30XD01 AA59126/30XD01
15-214-11-05
15-214-11-05
15-214-11-05
0.193" - Swage Mount 0.037" 1/64 0.067 Brass Electro Solder M55155/30XH01 AA59126/30XH01
15R-214-11-095
15R-214-11-095
15R-214-11-095
0.193" - Swage Mount 0.037" 1/64 0.067 Phosphor Bronze Hot Solder Dip M55155/30XC01 AA59126/30XC01
15-270-8-088
15-270-8-088
15-270-8-088
0.657" - Swage Mount 0.298" 1/4 0.116 Brass Bright Tin-Lead M55155/30XJ21 AA59126/30XJ21
15-270-4-088
15-270-4-088
15-270-4-088
0.530" - Swage Mount 0.171" 1/8 0.116 Brass Bright Tin-Lead M55155/30XJ15 AA59126/30XJ15
15-270-1-088
15-270-1-088
15-270-1-088
0.437" - Swage Mount 0.078" 1/32 0.116 Brass Bright Tin-Lead M55155/30XJ04 AA59126/30XJ04
15-209-6-088
15-209-6-088
15-209-6-088
0.452" - Swage Mount 0.234" 3/16 0.094 Brass Bright Tin-Lead M55155/30XJ17 AA59126/30XJ17
15-209-2-088
15-209-2-088
15-209-2-088
0.327" - Swage Mount 0.109" 1/16 0.094 Brass Bright Tin-Lead M55155/30XJ06 AA59126/30XJ06
15-209-1-088
15-209-1-088
15-209-1-088
0.296" - Swage Mount 0.078" 1/32 0.094 Brass Bright Tin-Lead M55155/30XJ03 AA59126/30XJ03
15-270-6-088
15-270-6-088
15-270-6-088
0.593" - Swage Mount 0.234" 3/16 0.116 Brass Bright Tin-Lead M55155/30XJ18 AA59126/30XJ18
15-214-4-088
15-214-4-088
15-214-4-088
0.303" - Swage Mount 0.147" 1/8 0.067 Brass Bright Tin-Lead M55155/30XJ13 AA59126/30XJ13
15-270-2-05
15-270-2-05
15-270-2-05
0.468" - Swage Mount 0.109" 1/16 0.116 Brass Electro Solder M55155/30XH07 AA59126/30XH07
15-209-2-05
15-209-2-05
15-209-2-05
0.327" - Swage Mount 0.109" 1/16 0.094 Brass Electro Solder M55155/30XH06 AA59126/30XH06
15R-211-8-05
15R-211-8-05
15R-211-8-05
0.796" - Swage Mount 0.296" 1/4 0.266 Phosphor Bronze Electro Solder M55155/30XB22 AA59226/30XB22
15-270-8-05
15-270-8-05
15-270-8-05
0.657" - Swage Mount 0.298" 1/4 0.116 Brass Electro Solder M55155/30XH21 AA59126/30XH21
15-211-6-05
15-211-6-05
15-211-6-05
0.734" - Swage Mount 0.234" 3/16 0.266 Brass Electro Solder M55155/30XH19 AA59196/30XH19
15-270-6-05
15-270-6-05
15-270-6-05
0.593" - Swage Mount 0.234" 3/16 0.116 Brass Electro Solder M55155/30XH18 AA59126/30XH18
15-141-3-095
15-141-3-095
15-141-3-095
0.209" - Swage Mount 0.115" 3/32 0.067 Brass Hot Solder Dip M55155/11XI06 AA59126/11XI06
