Commercial
Non-Insulated
Terminals

09-0191-2-04
09-0191-2-04
09-0191-2-04
0.300" - - Swage Mount 0.091" 1/16 0.041 Brass Electro-Tin YES
09-8045-2-04
09-8045-2-04
09-8045-2-04
0.252" 0.031 - Swage Mount 0.082" 1/16 0.043 Brass Electro-Tin YES
09-8055-1-04
09-8055-1-04
09-8055-1-04
0.651" 0.0305 - Swage Mount 0.051" 1/32 0.043 Brass Electro-Tin YES
10-103-8-04
10-103-8-04
10-103-8-04
0.531" - - Swage Mount 0.297" 1/4 0.116 Brass Electro-Tin YES
10-834-8-04
10-834-8-04
10-834-8-04
0.656" 0.050 - Swage Mount 0.281" 1/4 0.064 Brass Electro-Tin YES
09-0271-1-044
09-0271-1-044
09-0271-1-044
0.130" 0.029 (+0.003/-0.001) - - 0.115" - - Brass Bright Tin YES
09-0049-2-044
09-0049-2-044
09-0049-2-044
0.296" - - Press Fit/Solder 0.078" 1/16 0.073 Brass Bright Tin YES
10-892-1-044
10-892-1-044
10-892-1-044
0.651" 0.0405 - Swage Mount 0.051" 1/32 0.043 Brass Bright Tin YES
09-8154-2-035
09-8154-2-035
09-8154-2-035
0.714" 0.040 - Swage Mount 0.091" 1/16 0.043 Brass Gold YES
09-0176-1-01
09-0176-1-01
09-0176-1-01
0.112" - - Swage Mount 0.051" 1/32 0.052 Brass Silver YES
10-453-11-044
10-453-11-044
10-453-11-044
0.129" - - Swage Mount 0.035" 1/64 0.052 Brass Bright Tin YES
10-936-4-044
10-936-4-044
10-936-4-044
0.240" - - Swage Mount 0.147" 1/8 0.052 Brass Bright Tin YES
10-936-11-04
10-936-11-04
10-936-11-04
0.134" - - Swage Mount 0.037" 1/64 0.052 Brass Electro-Tin YES
09-8073-2-035
09-8073-2-035
09-8073-2-035
0.340" 0.050 - Swage Mount 0.082" 1/16 0.052 Brass Gold YES
09-7017-3-088
09-7017-3-088
09-7017-3-088
0.285" - - Swage Mount 0.125" 3/32 0.055 LEADED Red Brass Bright Tin-Lead NO
09-0269-2-088
09-0269-2-088
09-0269-2-088
0.265" - - Press Fit/Solder 0.130" 1/16 TO 3/32 0.055 Brass Bright Tin-Lead NO
09-6005-1-03
09-6005-1-03
09-6005-1-03
0.670" 0.025 SQ. TURRET/SQUARE-WRAP PC PIN Press Fit/Solder 0.080" 1/16 0.055 Brass Gold YES
09-8632-1-035
09-8632-1-035
09-8632-1-035
0.794" 0.032 - Swage Mount 0.051" 1/32 0.055 Brass Gold YES
10-541-4-088
10-541-4-088
10-541-4-088
0.634" - TURRET/DOUBLE TURRET Swage Mount 0.165" 1/8 0.116 Brass Bright Tin-Lead NO
09-0252-2-088
09-0252-2-088
09-0252-2-088
0.186" - - Swage Mount 0.082" 1/16 0.081 Brass Bright Tin-Lead NO

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
