Non-Insulated
PC Jacks

Filter
09-9045-6-03
09-9045-6-03
09-9045-6-03
0.025 0.141 " 0.397" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9045-6-06
09-9045-6-06
09-9045-6-06
0.025 0.141 " 0.397" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9045-6-063
09-9045-6-063
09-9045-6-063
0.025 0.141 " 0.397" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9273-1-04
09-9273-1-04
09-9273-1-04
0.030 0.165 " 0.250" - Solder - 1/32 - 1/8 0.076 Brass Electro-Tin Vertical
09-9628-1-063
09-9628-1-063
09-9628-1-063
0.025 - 0.037 0.063 " 0.095" - Solder - 1/32 - 1/16 0.0625 Brass Bright Tin-Lead Vertical
09-9628-1-035
09-9628-1-035
09-9628-1-035
0.025 - 0.037 0.063 " 0.095" - Solder - 1/32 - 1/16 0.0625 Brass Gold Vertical
09-9628-2-06
09-9628-2-06
09-9628-2-06
0.025 - 0.037 0.070 " 0.105" - Solder - 1/32 - 1/16 0.0625 Brass Electro-Tin Vertical
09-9045-2-03
09-9045-2-03
09-9045-2-03
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9045-2-035
09-9045-2-035
09-9045-2-035
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9045-2-063
09-9045-2-063
09-9045-2-063
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9045-2-088
09-9045-2-088
09-9045-2-088
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9045-2-06
09-9045-2-06
09-9045-2-06
0.025 0.141 " 0.303" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9628-3-04
09-9628-3-04
09-9628-3-04
0.025 - 0.037 0.116 " 0.155" - Solder - 1/32 - 3/32 0.0625 Brass Electro-Tin Vertical
09-9628-3-035
09-9628-3-035
09-9628-3-035
0.025 - 0.037 0.116 " 0.155" - Solder - 1/32 - 3/32 0.0625 Brass Gold Vertical
09-9284-1-035
09-9284-1-035
09-9284-1-035
0.080 0.350 " 0.466" - - - - - Brass Gold -
09-9037-6-06
09-9037-6-06
09-9037-6-06
0.030 - 0.032 0.183 " 0.515" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9037-6-063
09-9037-6-063
09-9037-6-063
0.030 - 0.032 0.183 " 0.515" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-4-088
09-9005-4-088
09-9005-4-088
0.040 0.190 " 0.543" Jack/Pin Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9003-4-06
09-9003-4-06
09-9003-4-06
0.040 0.195 " 0.432" Jack/Slotted Swage Mount 0.156" 1/8 0.129 Brass Electro-Tin Vertical
09-9042-1-03
09-9042-1-03
09-9042-1-03
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Gold Vertical
