Non-Insulated
PC Jacks

Filter
09-9169-1-035
09-9169-1-035
09-9169-1-035
0.030 0.190 " 0.206" - Press Fit/Solder - 3/32 - 5/32 0.076 Brass Gold Vertical
09-9065-1-04
09-9065-1-04
09-9065-1-04
0.040 0.211 " 0.411" Jack/Pin Solder - 1/32 - 1/16 0.038 Brass Electro-Tin Horizontal
09-9606-1-04
09-9606-1-04
09-9606-1-04
0.032 - 0.046 0.195 " 0.220" - Press Fit/Solder - 1/16 - 1/8 0.076 Brass Electro-Tin Vertical
09-9722-1-088
09-9722-1-088
09-9722-1-088
0.032 - 0.047 0.180 " 0.206" - Press Fit/Solder - 1/16 - 5/32 0.076 Brass Bright Tin-Lead Vertical
09-9722-1-03
09-9722-1-03
09-9722-1-03
0.032 - 0.047 0.180 " 0.206" - Press Fit/Solder - 1/16 - 5/32 0.076 Brass Gold Vertical
09-9722-1-04
09-9722-1-04
09-9722-1-04
0.032 - 0.047 0.180 " 0.206" - Press Fit/Solder - 1/16 - 5/32 0.076 Brass Electro-Tin Vertical
09-9247-1-04
09-9247-1-04
09-9247-1-04
0.040 0.185 " 0.219" - Press Fit/Solder - 1/32 - 1/16 0.076 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9247-1-06
09-9247-1-06
09-9247-1-06
0.040 0.185 " 0.219" - Press Fit/Solder - 1/32 - 1/16 0.076 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9248-1-04
09-9248-1-04
09-9248-1-04
0.040 0.185 " 0.220" - Press Fit/Solder - 1/32 - 1/16 0.076 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9169-1-06
09-9169-1-06
09-9169-1-06
0.030 0.190 " 0.206" - Press Fit/Solder - 3/32 - 5/32 0.076 Brass Electro-Tin Vertical
09-9079-1-03
09-9079-1-03
09-9079-1-03
0.040 0.190 " 0.206" - Press Fit/Solder - 3/32 - 5/32 0.076 Brass Gold Vertical
09-9053-1-063
09-9053-1-063
09-9053-1-063
0.040 0.185 " 0.240" Jack/Turret Press Fit/Solder - 1/32 - 5/32 0.076 Brass Bright Tin-Lead Vertical
09-9053-1-035
09-9053-1-035
09-9053-1-035
0.040 0.185 " 0.240" Jack/Turret Press Fit/Solder - 1/32 - 5/32 0.076 Brass Gold Vertical
09-9606-1-03
09-9606-1-03
09-9606-1-03
0.032 - 0.046 0.195 " 0.220" - Press Fit/Solder - 1/16 - 1/8 0.076 Brass Gold Vertical
09-9606-1-063
09-9606-1-063
09-9606-1-063
0.032 - 0.046 0.195 " 0.220" - Press Fit/Solder - 1/16 - 1/8 0.076 Brass Bright Tin-Lead Vertical
09-9726-1-063
09-9726-1-063
09-9726-1-063
0.032 - 0.046 0.200 " 0.226" - Solder - 1/32 - 3/16 0.076 Brass Bright Tin-Lead Vertical
09-9281-1-088
09-9281-1-088
09-9281-1-088
0.030 - 0.032 0.190 " 0.388" Jack/Turret Solder - 1/32 - 5/32 0.076 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9076-1-04
09-9076-1-04
09-9076-1-04
0.040 0.185 " 0.855" Jack/Square Wrap Pin Press Fit/Solder - 1/16 - 5/32 0.089 Brass Electro-Tin Vertical
09-9651-1-04
09-9651-1-04
09-9651-1-04
0.015 - 0.021 0.093 " 0.156" Jack/Pin Press Fit/Solder - 1/32 - 1/16 0.043 Phosphor Bronze Electro-Tin Vertical
09-9651-1-06
09-9651-1-06
09-9651-1-06
0.015 - 0.021 0.093 " 0.156" Jack/Pin Press Fit/Solder - 1/32 - 1/16 0.043 Phosphor Bronze Electro-Tin Vertical
