Non-Insulated
PC Jacks

09-9042-4-088
09-9042-4-088
09-9042-4-088
0.080 0.375 " 0.699" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9042-1-088
09-9042-1-088
09-9042-1-088
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9042-6-035
09-9042-6-035
09-9042-6-035
0.080 0.375 " 0.762" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9042-1-035
09-9042-1-035
09-9042-1-035
0.080 0.375 " 0.605" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9683-1-035
09-9683-1-035
09-9683-1-035
0.015 - 0.025 0.130 " 0.190" - Solder - 1/32 - 1/8 0.056 Brass Gold Vertical
09-9017-1-04
09-9017-1-04
09-9017-1-04
0.025 0.128 " 0.192" - Solder - 1/32 - 1/16 0.062 Brass Electro-Tin Vertical
09-9031-1-04
09-9031-1-04
09-9031-1-04
0.030 - 0.032 0.185 " 0.250" - Press Fit/Solder - 1/16 - 3/16 0.089 Brass Electro-Tin Vertical
09-9632-1-04
09-9632-1-04
09-9632-1-04
0.032 - 0.046 0.190 " 0.250" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Electro-Tin Vertical
09-9632-1-088
09-9632-1-088
09-9632-1-088
0.032 - 0.046 0.190 " 0.250" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Bright Tin-Lead Vertical
09-9632-1-06
09-9632-1-06
09-9632-1-06
0.032 - 0.046 0.190 " 0.250" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Electro-Tin Vertical
09-9632-1-03
09-9632-1-03
09-9632-1-03
0.032 - 0.046 0.190 " 0.250" - Press Fit/Solder - 1/16 - 5/32 0.090 Brass Gold Vertical
09-9139-1-035
09-9139-1-035
09-9139-1-035
0.040 0.185 " 0.855" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.089 Brass Gold Vertical
09-9653-1-063
09-9653-1-063
09-9653-1-063
0.032 - 0.046 0.190 " 0.343" Jack/Turret Press Fit/Solder - 1/16 - 5/32 0.090 Brass Bright Tin-Lead Vertical
09-9653-1-035
09-9653-1-035
09-9653-1-035
0.032 - 0.046 0.190 " 0.343" Jack/Turret Press Fit/Solder - 1/16 - 5/32 0.090 Brass Gold Vertical
09-9653-1-03
09-9653-1-03
09-9653-1-03
0.032 - 0.046 0.190 " 0.343" Jack/Turret Press Fit/Solder - 1/16 - 5/32 0.090 Brass Gold Vertical
09-9139-1-04
09-9139-1-04
09-9139-1-04
0.040 0.185 " 0.855" Jack/Pin Press Fit/Solder - 1/16 - 5/32 0.089 Brass Electro-Tin Vertical
09-9604-6-03
09-9604-6-03
09-9604-6-03
0.032 - 0.046 0.200 " 0.517" Jack/Turret Swage Mount 0.219" 3/16 0.094 Brass Gold Vertical
09-9604-4-063
09-9604-4-063
09-9604-4-063
0.032 - 0.046 0.200 " 0.454" Jack/Turret Swage Mount 0.156" 1/8 0.094 Brass Bright Tin-Lead Vertical
09-9604-3-03
09-9604-3-03
09-9604-3-03
0.032 - 0.046 0.200 " 0.423" Jack/Turret Swage Mount 0.125" 3/32 0.094 Brass Gold Vertical
09-9604-6-088
09-9604-6-088
09-9604-6-088
0.032 - 0.046 0.200 " 0.517" Jack/Turret Swage Mount 0.219" 3/16 0.094 Brass Bright Tin-Lead Vertical
