Non-Insulated
PC Jacks

09-9004-2-03
09-9004-2-03
09-9004-2-03
0.040 0.183 " 0.397" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9004-3-04
09-9004-3-04
09-9004-3-04
0.040 0.183 " 0.428" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9004-1-03
09-9004-1-03
09-9004-1-03
0.040 0.183 " 0.365" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9004-4-03
09-9004-4-03
09-9004-4-03
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9005-2-063
09-9005-2-063
09-9005-2-063
0.040 0.190 " 0.481" Jack/Pin Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-3-063
09-9005-3-063
09-9005-3-063
0.040 0.190 " 0.512" Jack/Pin Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-4-088
09-9005-4-088
09-9005-4-088
0.040 0.190 " 0.543" Jack/Pin Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-4-063
09-9005-4-063
09-9005-4-063
0.040 0.190 " 0.543" Jack/Pin Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-6-03
09-9005-6-03
09-9005-6-03
0.040 0.190 " 0.606" Jack/Pin Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9005-3-035
09-9005-3-035
09-9005-3-035
0.040 0.190 " 0.512" Jack/Pin Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9005-1-088
09-9005-1-088
09-9005-1-088
0.040 0.190 " 0.449" Jack/Pin Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9005-1-06
09-9005-1-06
09-9005-1-06
0.040 0.190 " 0.449" Jack/Pin Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9005-3-06
09-9005-3-06
09-9005-3-06
0.040 0.190 " 0.512" Jack/Pin Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9005-4-04
09-9005-4-04
09-9005-4-04
0.040 0.190 " 0.543" Jack/Pin Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9005-2-03
09-9005-2-03
09-9005-2-03
0.040 0.190 " 0.481" Jack/Pin Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9005-6-06
09-9005-6-06
09-9005-6-06
0.040 0.190 " 0.606" Jack/Pin Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9005-4-03
09-9005-4-03
09-9005-4-03
0.040 0.190 " 0.543" Jack/Pin Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9005-6-035
09-9005-6-035
09-9005-6-035
0.040 0.190 " 0.606" Jack/Pin Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9037-3-063
09-9037-3-063
09-9037-3-063
0.030 - 0.032 0.183 " 0.421" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9037-2-063
09-9037-2-063
09-9037-2-063
0.030 - 0.032 0.183 " 0.390" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
