Non-Insulated
PC Jacks

09-9736-1-063
09-9736-1-063
09-9736-1-063
0.032 - 0.046 0.250 " 0.296" - Solder - 1/32 - 5/32 0.089 Brass Bright Tin-Lead Vertical
09-9018-1-035
09-9018-1-035
09-9018-1-035
0.040 0.190 " 0.236" - Solder - 1/32 - 5/32 0.089 (+0.002/-0.001) Brass Gold Vertical
09-9067-4-06
09-9067-4-06
09-9067-4-06
0.060 - 0.062 0.204 " 0.506" Jack/Turret Swage Mount 0.151" 1/8 0.144 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9729-1-035
09-9729-1-035
09-9729-1-035
0.032 - 0.046 0.220 " 0.253" - Solder - 1/32 - 3/16 0.0935 Brass Gold Vertical
09-9730-1-035
09-9730-1-035
09-9730-1-035
0.032 - 0.046 0.200 " 0.240" - Solder - 1/32 - 3/16 0.089 Brass Gold Vertical
09-9742-1-063
09-9742-1-063
09-9742-1-063
0.032 - 0.046 0.166 " 0.250" - Press Fit/Solder - 3/32 - 1/8 0.089 Brass Bright Tin-Lead Vertical
09-9004-6-03
09-9004-6-03
09-9004-6-03
0.040 0.183 " 0.522" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9004-4-063
09-9004-4-063
09-9004-4-063
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9004-3-063
09-9004-3-063
09-9004-3-063
0.040 0.183 " 0.428" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9047-1-088
09-9047-1-088
09-9047-1-088
0.040 0.186 " 0.233" - Solder - 1/32 - 1/8 0.104 Brass Bright Tin-Lead Vertical
09-9004-2-063
09-9004-2-063
09-9004-2-063
0.040 0.183 " 0.397" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9004-1-06
09-9004-1-06
09-9004-1-06
0.040 0.183 " 0.365" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9004-6-088
09-9004-6-088
09-9004-6-088
0.040 0.183 " 0.522" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9004-4-088
09-9004-4-088
09-9004-4-088
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Bright Tin-Lead Vertical
09-9004-4-035
09-9004-4-035
09-9004-4-035
0.040 0.183 " 0.459" Jack/Turret Swage Mount 0.156" 1/8 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9004-6-035
09-9004-6-035
09-9004-6-035
0.040 0.183 " 0.522" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9004-1-035
09-9004-1-035
09-9004-1-035
0.040 0.183 " 0.365" Jack/Turret Swage Mount 0.062" 1/32 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9004-6-04
09-9004-6-04
09-9004-6-04
0.040 0.183 " 0.522" Jack/Turret Swage Mount 0.219" 3/16 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
09-9004-2-035
09-9004-2-035
09-9004-2-035
0.040 0.183 " 0.397" Jack/Turret Swage Mount 0.094" 1/16 0.094 (+0.002/-0.001) Brass Gold Vertical
09-9004-3-06
09-9004-3-06
09-9004-3-06
0.040 0.183 " 0.428" Jack/Turret Swage Mount 0.125" 3/32 0.094 (+0.002/-0.001) Brass Electro-Tin Vertical
