Panel Jacks / Terminals
Thread Mount

Filter
09-9152-1-0314
09-9152-1-0314
09-9152-1-0314
1.170" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   Yellow -
09-9152-1-04411
09-9152-1-04411
09-9152-1-04411
1.170" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Bright Tin - - Nylon   Brown -
09-9152-1-0317
09-9152-1-0317
09-9152-1-0317
1.170" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   Violet -
09-9152-1-04413
09-9152-1-04413
09-9152-1-04413
1.170" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Bright Tin - - Nylon   Orange -
09-9152-1-04418
09-9152-1-04418
09-9152-1-04418
1.170" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Bright Tin - - Nylon   Gray -
09-9124-1-0212
09-9124-1-0212
09-9124-1-0212
1.000" 0.080 1/4-32 Nut 0.550 " 0.257 1/8 Jack/Eyelet - - Phosphor Bronze UNPLATED Nylon   Red -
09-9152-1-0313
09-9152-1-0313
09-9152-1-0313
1.170" - 1/4-32 Nut - 0.257 Up to 3/16 Turret/Turret Brass Gold - - Nylon   Orange -
09-9074-1-03514
09-9074-1-03514
09-9074-1-03514
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Yellow MIL-DTL-39024/10
09-9243-1-03517
09-9243-1-03517
09-9243-1-03517
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Violet MIL-DTL-39024/10
09-9228-1-03518
09-9228-1-03518
09-9228-1-03518
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Gray MIL-DTL-39024/10
09-9243-1-03518
09-9243-1-03518
09-9243-1-03518
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Gray MIL-DTL-39024/10
09-9072-1-03519
09-9072-1-03519
09-9072-1-03519
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   White MIL-DTL-39024/10
09-9072-1-03515
09-9072-1-03515
09-9072-1-03515
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Green MIL-DTL-39024/10
09-9243-1-03513
09-9243-1-03513
09-9243-1-03513
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Orange MIL-DTL-39024/10
09-9243-1-03515
09-9243-1-03515
09-9243-1-03515
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Green MIL-DTL-39024/10
09-9072-1-03511
09-9072-1-03511
09-9072-1-03511
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Brown MIL-DTL-39024/10
09-9228-1-03516
09-9228-1-03516
09-9228-1-03516
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Blue MIL-DTL-39024/10
09-9243-1-03514
09-9243-1-03514
09-9243-1-03514
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Yellow MIL-DTL-39024/10
09-9243-1-03516
09-9243-1-03516
09-9243-1-03516
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold WITH Solder COATED TIP Beryllium Copper Gold Nylon   Blue MIL-DTL-39024/10
09-9075-1-0314
09-9075-1-0314
09-9075-1-0314
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold PTFE Yellow -
