Panel Jacks / Terminals
Thread Mount

Filter
20-2124-1-03515
20-2124-1-03515
20-2124-1-03515
0.905" 0.060 5/16-32 Nut 0.500 " 0.323 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Green -
09-9151-1-03510
09-9151-1-03510
09-9151-1-03510
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Black -
09-9151-1-03513
09-9151-1-03513
09-9151-1-03513
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Orange -
09-9150-1-03517
09-9150-1-03517
09-9150-1-03517
0.9375" 0.080 1/4-32 Nut 0.370 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Violet -
09-9183-1-03513
09-9183-1-03513
09-9183-1-03513
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Orange -
09-9151-1-03519
09-9151-1-03519
09-9151-1-03519
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   White -
09-9184-1-03511
09-9184-1-03511
09-9184-1-03511
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Brown -
09-9184-1-03516
09-9184-1-03516
09-9184-1-03516
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Eyelet Brass Gold Beryllium Copper Gold Nylon   Blue -
09-9150-1-03512
09-9150-1-03512
09-9150-1-03512
0.9375" 0.080 1/4-32 Nut 0.370 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Red -
09-9150-1-0311
09-9150-1-0311
09-9150-1-0311
0.9375" 0.080 1/4-32 Nut 0.370 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Brown -
09-9183-1-04419
09-9183-1-04419
09-9183-1-04419
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Turret Brass Bright Tin Beryllium Copper Bright Tin Nylon   White -
09-9183-1-04413
09-9183-1-04413
09-9183-1-04413
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Turret Brass Bright Tin Beryllium Copper Bright Tin Nylon   Orange -
09-9151-1-04417
09-9151-1-04417
09-9151-1-04417
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Violet -
09-9150-1-0312
09-9150-1-0312
09-9150-1-0312
0.9375" 0.080 1/4-32 Nut 0.370 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold Nylon   Red -
09-9183-1-04418
09-9183-1-04418
09-9183-1-04418
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Turret Brass Bright Tin Beryllium Copper Bright Tin Nylon   Gray -
09-9184-1-04416
09-9184-1-04416
09-9184-1-04416
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Blue -
09-9124-1-0210
09-9124-1-0210
09-9124-1-0210
1.000" 0.080 1/4-32 Nut 0.550 " 0.257 1/8 Jack/Eyelet - - Phosphor Bronze UNPLATED Nylon   Black -
09-9151-1-04410
09-9151-1-04410
09-9151-1-04410
0.9375" 0.080 1/4-32 Nut 0.375 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Black -
09-9184-1-04418
09-9184-1-04418
09-9184-1-04418
0.975" 0.080 1/4-32 Nut 0.620 " 0.257 Up to 3/16 Jack/Eyelet Brass Bright Tin Beryllium Copper Bright Tin Nylon   Gray -
09-9075-1-0314
09-9075-1-0314
09-9075-1-0314
0.922" 0.080 1/4-32 Nut 0.420 " 0.257 Up to 3/16 Jack/Turret Brass Gold Beryllium Copper Gold PTFE Yellow -
