Insulated
Banana Jacks

09-9140-1-04413
09-9140-1-04413
09-9140-1-04413
0.938" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 x 0.230 Brass Bright Tin - Nylon Orange
25-9231-1-04415
25-9231-1-04415
25-9231-1-04415
1.220" Standard 0.920 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin - Polycarbonate Green
09-9140-1-04411
09-9140-1-04411
09-9140-1-04411
0.938" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 x 0.230 Brass Bright Tin - Nylon Brown
09-9141-1-0317
09-9141-1-0317
09-9141-1-0317
1.016" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 Brass Gold - Nylon Violet
09-9141-1-0316
09-9141-1-0316
09-9141-1-0316
1.016" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 Brass Gold - Nylon Blue
09-9141-1-0315
09-9141-1-0315
09-9141-1-0315
1.016" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 Brass Gold - Nylon Green
25-9231-1-04416
25-9231-1-04416
25-9231-1-04416
1.220" Standard 0.920 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin - Polycarbonate Blue
25-9235-1-04413
25-9235-1-04413
25-9235-1-04413
1.670" Standard 0.760 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin Bright Tin Polycarbonate Orange
25-9235-1-04412
25-9235-1-04412
25-9235-1-04412
1.670" Standard 0.760 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin Bright Tin Polycarbonate Red
25-9235-1-04419
25-9235-1-04419
25-9235-1-04419
1.670" Standard 0.760 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin Bright Tin Polycarbonate White
25-9235-1-04411
25-9235-1-04411
25-9235-1-04411
1.670" Standard 0.760 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin Bright Tin Polycarbonate Brown
09-9140-1-04412
09-9140-1-04412
09-9140-1-04412
0.938" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 x 0.230 Brass Bright Tin - Nylon Red
25-9231-1-0319
25-9231-1-0319
25-9231-1-0319
1.220" Standard 0.920 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Gold - Polycarbonate White
25-9231-1-0313
25-9231-1-0313
25-9231-1-0313
1.220" Standard 0.920 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Gold - Polycarbonate Orange
25-9231-1-04417
25-9231-1-04417
25-9231-1-04417
1.220" Standard 0.920 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin - Polycarbonate Violet
09-9141-1-0314
09-9141-1-0314
09-9141-1-0314
1.016" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 Brass Gold - Nylon Yellow
25-9231-1-04411
25-9231-1-04411
25-9231-1-04411
1.220" Standard 0.920 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Bright Tin - Polycarbonate Brown
09-9141-1-0310
09-9141-1-0310
09-9141-1-0310
1.016" Miniature 0.320 " 1/4-32 Nut Up to 1/4 0.257 Brass Gold - Nylon Black
25-9231-1-0312
25-9231-1-0312
25-9231-1-0312
1.220" Standard 0.920 " 1/4-32 Nut Up to 3/8 0.375 x 0.350D HOLE Brass Gold - Polycarbonate Red
09-9126-1-0314
09-9126-1-0314
09-9126-1-0314
0.922" Standard 0.596 " 5/16-32 Nut Up to 5/16 0.312 x 0.250 Red Brass (85% Cu) Gold - Nylon Yellow

About the Company

CONCORD ELECTRONICS, INC. is a leading manufacturer of high reliability, precision-machined interconnect components, hardware and test accessories. A majority of our parts are proudly Made in the USA and used in a wide variety of industries including: automotive, avionics, energy, industrial, instrumentation, marine, medical, military and telecommunications.  We are a MIL-DTL-39024 recognized manufacturer of both MIL-T-55155 (Group A) and A-A-59126 components
